High-performance, easy operation and ergonomically designed sterilizer featuringeasy top loading and handling of samples
Features of Steam Sterilizer (Laboratory Use, Compact) (SN200)
Steam Sterilizer (Laboratory Use, Compact) (SN200)
Description
- Features
- Maximum sterilizing temperature goes up to 135°C
suitable for protein modification - Features
- By simple setting and operation, these sterilizers
manage ordinary sterilization, sterilization
of culture mediums and liquids, and melting of
culture mediums - Features
- Custom programs can be saved for repeated
use - Features
- Standard equipped with timer start and pre-heating
features for the efficient use of time and cooling
fan to shorten cool down timetime - Features
- Mobile on wheels
- Enhanced safety device
- ,Lid interlock mechanism
, Drain bottle unset alarm
, Memory malfunction
, Automatic shutdown when malfunctioning
,Self-diagnostic functions
| Model | SN200 |
|---|---|
| System | Automatic high-pressure steam sterilization |
| Operating temperature range | 45～135℃ 45～80℃（Preheating temperature）/45～60℃（Heat-retention process）/65～100℃（Solution process）/105～135℃（Sterilization） |
| Max. working pressure | 0.255MPa |
| Ambient temperature | 5～35℃ |
| Lid | Manual upward opening with an interlock for safety |
| Heater | 100V, 600W×2 units |
| Exhaust valve | One exhaust valve and one slow release valve |
| Connection ports for optional accessories | Total 3 ports. Female thread for sample temp. sensor (1/4″ ), Female thread for chamber temp. sensor (1/4″ ), Female thread pressure sensor (Branching from the solenoid valve tubing) |
| Cooling fan | Axial fan motor |
| Temp. controller | PID control by microprocessor |
| Temp. display / setting | Digital display / digital setting by ▲/▼ keys |
| Timer / Timer resolution | 0 or 1 min. to 99 hrs 59 min. / 1 min. |
| Operation mode | Instrument sterilization course, Liquid sterilization course, Sterilization and keep warm course, Melting and keep warm course, Customer-programmed course |
| Other function | Key locking, Presetting, Saving, Preheating, Forced cooling, Sample temperature sensor (option), Pattern locking, Up to 20 error log saving, Display of accumulated working time / Present time, ON-OFF beeping setting |
| Safety device | Sensor failure detection, SSR short-circuit, Broken heater wire, Prevention of idle heating (Liquid expansion type), Alarm against the absence of a drain bottle, Failure in locking the lid, Memory error detection, Pressure relief valve (0.255 MPa) |
| Accessories | 2 pcs. stainless steel mesh basket (Dia.209×D204mm), OSM-60/Vapor cup×1, Drain bottle×1, Drain board×1, Filter×1 |
| Internal dimensions（φ×H mm） | φ240×445mm |
| External dimensions（W×D×H mm） | 400×530×840mm |
| Remarks(dimensions) | Internal capacity 20L |
| Power Source | AC100～120V Single phase |
| Weight | 65kg |
