Reverse Osmosis And Ultrafiltration Pilot Plant Didactic Equipment Teaching Equipment Water Treatment Training Equipment

Description

MR007W Reverse Osmosis And Ultrafiltration Pilot Plant Didactic Equipment Teaching Equipment Water Treatment Training Equipment

This unit is a flexible system for studying the reverse osmosis and ultrafi ltration on a wide range of operating conditions.
• Framework of AISI 304 stainless steel with castors
• Feeding tank of AISI 304 stainless steel with capacity of 30 litres
• Tank of AISI 304 stainless steel, with capacity of 30 litres, for permeate
• Piston pump of AISI 316 stainless steel
• AISI 316 stainless steel housing for 2 membranes; typical fl ow of permeate = 5-50 ml/min

• Heat exchanger of AISI 304 stainless steel
• 2 variable area flowmeters for permeate and concentrate
• 4 Pt100 with sheath of AISI 316 stainless steel
• 2 Bourdon gauges of AISI 304 stainless steel
• Safety valve
• Safety pressure switch
• Switchboard with ELCB

Besides being provided with all the characteristics of, this model also includes the following additional items:
• 2 flowmeters with transmitter
• 2 pressure transmitters of stainless steel
• Interface for the connection with a PC included in the switchboard
• Data acquisition software for Windows
Dimensions: 850 × 600 × 1500 mm
Weight: 80 kg
Supplied theoretical-experimental manual
Installation, Training and Commisisoning is required.
