Best selling incubator for low temperature tests and environmental tests
Features of Low Temperature Incubator (Programmable) (IN604)
Best selling incubator for low temperature tests and environmental tests
Features of Low Temperature Incubator (Programmable) (IN604)
Standard low temperature incubator
Available for wide variety of applications from various constant temperature tests to environmental tests
Feature
Forced circulation with a fan enables high accuracy temperature control and even temperature distribution
Feature
The glass inner door keeps temperature changes during observation samples minimum
Model | IN604 |
---|---|
System | Forced air convection |
Operating Temperature Range | -10~50℃ |
Temperature Adjustment Accuracy | ±0.3℃(when refrigerator is in continuous operation), ±1.0℃(when refrigerator is in cycle operation) |
Temperature Distribution Accuracy | ±1.0℃(at 37℃ refrigerator is in continuous operation) |
Max. Temperature Reaching Time | 20~50℃ approx. 20min. |
Lowest Temperature Reaching Time | 20~-10℃ approx. 45min. |
Interior | Stainless Steel |
Exterior | Chrome-free electronic galvanized plated steel plate chemical-proof baking finish |
Heat Insulation Material | Stylene foam (non-freon) |
Refrigerator Medium | R134a |
Defrosting Mechanism | Manual ON / Auto OFF, Timer operation, Cycle operation |
Blower | Axial flow fan |
Heater | Iron-chrome wire heater 550W |
Sensor | Double sensor:Pt. resistance temperature detector, Pt100Ω(Temperature controller), K-thermocouple(Overheat prevention device) |
Cable Port | 32mm ID (Right side from the front) |
Temperature Control | PID control |
Temperature Setting | Digital setting with▲▼ key |
Temperature Display | Measured temperature: 4-digit orange LED digital display+ VFD fluorescent display |
Timer/Timer Resolution | 0~999 hrs. 59min. / 1min. |
Operation Function | Fixed operation, Program operation, Auto stop, Auto start |
Additional Function | Timer function(accumulated time to 49,999 hrs.), Calibration off-set function, Clock display |
Safety Device | Self-diagnostic functions(Temperature sensor error, Heater disconnection, SSR short-circuit, Main relay error, Automatic overheat prevention), Key-lock, Over current ELB, Overheat preventive device |
Shelf Loading Capacity | 15kg/shelf |
Shelf support step number | 13 steps |
Shelf support pitch | 30mm |
Shelf / Support | Stainless steel punching metal, 3 shelves / 6 supports |
Room Light / Service Outlet | – |
Program Mode | Up to 32 steps, Repeat, Gradient operation |
Door Key | – |
Internal dimensions(W×D×H mm) | 600×477×500mm |
External dimensions(W×D×H mm) | 710×645×913mm |
Remarks(dimensions) | 143L |
Power Source | AC115V/220V Single phase |
Weight | 89kg |
