Suitable for:
- ultra low cooling
Freezer SWUF-80 UniFreeze SmartLab 82 liters -86°C
Description
Technical features:
- compact, ultra-low temperature tabletop freezer
- Freezing down to -86°C
- CFC-free coolant
- Hole for external temperature sensor
- Blocking capacitor replaces filter
- less heat from the compressor thanks to the filterless system
- easy maintenance and improved performance
- high quality insulation panel and inner doors ensure defrosting on the outer surface
- Stainless steel interior & powder coated steel body
- CE, UL/CUL & RoHS certificate & with serial number for tracking
- IQ/OQ available
Safety device:
- Push alarm service to your smartphone
- Sensor error detection
- Door lock system, door opening error
- Door and power failure alarm
- Standard warning and alarm functions
Steering:
- SMART-Lab™ control with 7″ touchscreen TFT LCD:
- WiRe™ App Service, remote control system
- various program settings
- self-diagnostic function
- automatic data recording
- Data transfer via USB stick to the PC
- Internet connection through WiFi
Freezer SWUF-80, 1 stainless steel frame, power cord, instruction manual
features
UniFreezeTM System: Single compressor ensures temperatures down to -86°C, minimizes power consumption and noise levels.
Environmentally friendly product
RoHs certified: No hazardous substances (Pb, Cd, Hg, Hex-Cr, PBB, PBDE) are used in all UniFreezeTM and DuoFreezeTM cooling devices!
Natural Refrigerants: Instead of HFC refrigerants (R-134a, R-404A, R-507), all Uni-FreezeTM and DuoFreezeTM models have a specially blended refrigerant made primarily of natural materials.
Power Consumption: Up to 39% lower than the average competitor.
Smart LabTM control:
- TFT LCD full touch screen:
- WiRe™ App Service, remote control system
- various program settings
- Self-diagnosis and interactive temperature graph
- automatic data recording and password protection
- Data transfer via USB stick to the PC
- digital calibration (compensation function)
- Min./max. temperature memory & programming function
- Push alarm service to your smartphone or tablet
Devices with a mains voltage of 230 V can also be supplied with a voltage of 120 V on request.
execution
Max. number of racks: 4 pcs with 12 (3 x 4) racks (RFU8)
width (inside)
340mm
length (inside)
485mm
height (inside)
520mm
width (outside)
530mm
length (outside)
687mm
height (outside)
1060mm
suitable / suitable for
ultra low cooling
slots
1 stainless steel frame
capacity
82L
compressor
Hermetic execution
capacitor
Blocking capacitor, no pins, no filters
coolant
CFC-free
power consumption
321 W/h
temperature range
-86°C to -65°C, at 30°C room temperature & 70% humidity
packaging size
960x760x1350mm
sensor
Temperature sensor PT100
