Fine oven with an explosion preventive vent door.
Features of Fine Oven (with Explosion Vent) (DF412S)
Fine Oven (with Explosion Vent) (DF412S)
Description
Features
The product is equipped with a safety door to relief an explosion pressure (explosion preventive vent door) and an interlock door knob that reliably secure the main unit and the door.
Features
The product is integrated with the following interlock functions:
I) Operation can be started by closing the door with the door lock.
II) The main power will be shut off when the explosion detection switch on the ceiling is activated.
Features
Standard functions include program operation and other high precision functions.
Features
Improved safety functions include the self diagnostic function, the automatic overheat prevention function, and the key lock function
| Model | DF412S |
|---|---|
| Method | Forced convection and ventilation |
| Operating temp. range | RT+10°C to 260°C |
| Temp. gradient | 10℃（at 260℃） |
| Temperature control | PID control with a micro computer |
| Operation & control | Fixed temp., Auto-start, Auto-stop, Quick auto stop, program (Max.99 steps, 99 patterns, repeat) |
| Additional functions | Calendar timer (max. 24hrs.), Integration time (max. 65535hrs.), calibration off-set, Display the amount of power consumption/CO2 discharge / Heater operation amount, |
| Additional functions | Power failure recovery mode, User setting information save and recall, Wind velocity changeable function |
| Temp. sensor | K-thermocouple (double sensor) |
| Heater | Stainless pipe heater |
| Heater capacity | 2.1kW |
| Fan | Axial fan (Condenser motor: 20W) |
| Cable port | I.D. 30mm (rear panel) |
| Heat insulator | Glass wool |
| Other additional function | Explosion preventive vent door |
| Safety functions | Self diagnosis functions(Sensor, Fan, heater, Relay, Triac, Automatic overheat prevention), Independent overheat prevention, Key lock function, Electric leakage breaker, Door switch |
| Accessories Shelf | Stainless wire |
| Accessories Shelf | 2pcs. |
| Accessories Shelf support | 4pcs. |
| Internal dimensions（W×D×H mm） | 450×450×450mm |
| External dimensions（W×D×H mm） | 1050×620×1240mm |
| Remarks(dimensions) | 91L |
| Power Source | AC220V 10A Single-phase |
| Weight | 130kg |
