Clean Oven (DE411)

Clean oven suitable for temperature test in dust-free environment.

Features of Clean Oven (DE411)

Description

Features

Adoption of anti-fouling caster (preventing wheel contamination during transportation)

Features

Improvement of visibility of HEPA filter replacement timing by three color indication.

Features

Improvement of safety by phase-reversal relay, detecting of incorrect wiring of power supply when installing.

Features

Cable diameter changed from 30mm I.D to 33mm I.D when compare with conventional equipment.

Features

More options when compare with conventional equipment.

Model DE411
Temp. distribution accuracy ±2.5°C (at 260°C) JTM K05
Max. temp. reaching time Approx. 70 min. (at 260°C)
Heater Stainless pipe heater
Cable hole 33mm I.D. ×1
Timer 1 min. to 99 Hrs. 59 min
Operation function Fixed temp., Auto-start, Auto-stop, Quick auto stop, program (Max.99 steps, 99 patterns, repeat)
Circulation method Forced air circulation
Operating temperature range Room temperature +30~260°C
Temp. adjustment accuracy ±0.3°C (at 260°C) JTM K05
Temp. fluctuation 1.0°C (at 260°C) JIS
Temp. gradient ±10°C(at 260°C) JIS
Clean level Class 100 (when the temperature is stable)
Interior Stainless steel
Exterior material Cold rolled steel plate with melamine resin baking finish
Fan type Sirocco fan, Condenser type motor
Differential pressure meter Analog type (0~300 Pa)
Exhaust port 61mm O.D.×1
Filter Heat resistant HEPA filter (dust collect : more than 99.97% at 0.3μm )
Caster Wheel Dia. 50mm anti-fouling caster
Temp. controller PID control by micro processor
Temp. setting method Digital setting with UP/DOWN key
Temp display method Digital display
Other display Operation monitor (operation condition graphic display by LED patterns)
Additional functions Calendar timer (max. 24 Hrs.), Calibration off-set function, Integration time (max. 65535Hrs.), Display the amount of power consumption/CO2 discharge/Heater operation amount, Power failure recovery mode, User setting information save and recall
Heater circuit control Triac zero-cross control
Temp. sensor K-thermocouple (double sensor)
Safety countermeasures Self diagnosis functions (Sensor, Fan, Heater, Relay, Triac, Automatic overheat prevention), Independent overheat prevention, Key lock function, Electric leakage breaker, Door switch, Reverse phase protection
Shelf support step number 12 steps
Accessories Shelf plate Stainless wire steel, 2 pcs
Accessories Shelf support 4 pcs
Internal dimensions(W×D×H mm) 450×450×450mm
External dimensions(W×D×H mm) 700×1025×1570mm
Remarks(dimensions) 91L
Power Source AC220/380V
Three phase
Weight 200kg
